Electrical Design and Drafting Projects

We had to do electrical drafting of an eight storey residential and commercial Building in India, Singapore and Malaysia. It was a multipurpose building with Shops, Supermarkets, Play School, Power GYM and Offices.

We had to prepare Lighting cad drawings, Power Drawings, Power Distribution Drawings and Technology Drawings. The output was to be sent in AutoCAD 2004 to AutoCAD 2007 version. There was no library sent by the client.

We prepared our own library as per the client requirements. There were around 150 electrical drawings to be completed in a fortnight. The Tiff files sent by the clients were messy which increased the time spent on each drawing. So, to finish the project on time without compromising on quality was one of the challenges faced by our team.

Send us your electrical project requirements today at srkelectricaldesign@gmail.com

2D Electrical Basement Layout Services – Residential

2D Electrical Floor Layout Services – Residential

2D Electrical Structure Layout

2D Electrical DG Schematic Services – Residential

2D Electrical Structure Layout

2D Electrical Schematic Services – Residential (LT)
